The c3 package is a wrapper, or htmlwidget, for the C3 javascript charting library by Masayuki Tanaka. You will find this package useful if you are wanting to create a chart using R and embedding it in a Rmarkdown document or Shiny App.

The C3 library is very versatile and includes a lot of options. Currently this package wraps most of the C3 options object. Even with this current limitation a wide range of options are available.

Instalation

install.packages("c3")

# or

devtools::install_github("mrjoh3/c3")

Usage

The c3 package is intended to be as simple and lightweight as possible. As a starting point the data input must be a data.frame or tibble with several options.

If a data.frame without any options is passed all of the numeric columns will be plotted. This can be used in line and bar plots. Each column is a line or bar.
For more complex plots only 3 columns are used, those defined as x, y and group. This requires a data.frame with a vertical structure.

The Basics

Where no options are supplied a simple line plot is produced by default. Where no x-axis is defined the plots are sequential. Date x-axis can be parsed with not additional setting if in the format %Y-%m-%d (ie ‘2014-01-01’)

library(c3)

## Warning: package 'c3' was built under R version 4.1.3

##
## Attaching package: 'c3'

## The following objects are masked from 'package:graphics':
##
##     grid, legend

data = data.frame(a = abs(rnorm(20) * 10),
                  b = abs(rnorm(20) * 10),
                  date = seq(as.Date("2011-01-01"), by = "month", length.out = 20))
c3(data)

Piping

The package also imports the magrittr piping function (%>%) to simplify syntax.

data%>%c3()

Other Line Plots

There are 5 different line plots available:

line
spline
step
area
area-step

Spline

data %>%
  c3() %>%
  c3_line('spline')

Step

data %>%
  c3(x = 'date') %>%
  c3_line('area-step')

Bar Plots

data[1:10, ] %>%
  c3() %>%
  c3_bar(stacked = TRUE,
         rotate = TRUE)

Mixed Geometry Plots

Mixed geometry currently only works with a horizontal data.frame where each numeric column is plotted.

data$c <- abs(rnorm(20) *10)
data$d <- abs(rnorm(20) *10)
data %>%
  c3() %>%
  c3_mixedGeom(type = 'bar',
               stacked = c('b','d'),
               types = list(a='area',
                            c='spline')
               )

Secondary Y Axis

To use a secondary Y axis columns must first be matched to an axis and then the secondary axis made visible.

data %>%
  dplyr::select(date, a, b) %>%
  c3(x = 'date',
     axes = list(a = 'y',
                 b = 'y2')) %>%
  c3_mixedGeom(types = list(a = 'line',
                            b = 'area')) %>%
  y2Axis()

Scatter Plot

mtcars %>%
  c3(x = 'mpg',
     y = 'wt',
     group = 'cyl') %>%
  c3_scatter()

Pie Charts

data.frame(India = 45,
           Bangladesh = 20,
           SriLanka = 10) %>%
  c3() %>%
  c3_pie()

Donut Charts

data.frame(red = 82, green = 33, blue = 93) %>%
  c3(colors = list(red = 'red',
                   green = 'green',
                   blue = 'blue')) %>%
  c3_donut(title = '#d053ee')

Gauge Charts

data.frame(data = 80) %>%
  c3() %>%
  c3_gauge()

Grid Lines & Annotation

data %>%
  c3() %>%
  grid('y') %>%
  grid('x',
       show = F,
       lines = data.frame(value = c(3, 10),
                          text= c('Line 1','Line 2')))

Sub-chart

data %>%
  c3(x = 'date') %>%
  subchart()

Color Palette

Plot color palettes can be changed to either RColorBrewer or viridis palettes using either RColorBrewer (S3 method) or c3_viridus.

data.frame(sugar = 20,
           fat = 45,
           salt = 10,
           vegetables = 60) %>%
  c3() %>%
  c3_pie() %>%
  RColorBrewer()

data.frame(sugar = 20,
           fat = 45,
           salt = 10,
           vegetables = 60) %>%
  c3() %>%
  c3_pie() %>%
  c3_viridis()

Point Size

data %>%
  c3(x = 'date') %>%
  point_options(r = 6,
                expand.r = 2)

On Click

Onclick, onmouseover and onmouseout are all available via the c3 function. To use wrap a js function as a character string to htmlwidgets::JS(). Please see the C3.js documentation and examples. The example below should be enough to get you started.

data %>%
    c3(onclick = htmlwidgets::JS('function(d, element){console.log(d)}'))

Tooltips

C3 tooltips are readily modified with the use of javascript functions. For further detail see the C3.js documentation. Or for more advanced usage see the C3.js examples page.

library("htmlwidgets")

## Warning: package 'htmlwidgets' was built under R version 4.1.3

data %>%
  c3() %>%
  tooltip(format = list(title = JS("function (x) { return 'Data ' + x; }"),
                        name = JS('function (name, ratio, id, index) { return name; }'),
                        value = JS('function (value, ratio, id, index) { return ratio; }')))
